Feature Images
Official product promotional feature images.
Product Video
Open box video for Ruijie Reyee RG-NBS5100-24GT4SFP 28-Port Gigabit Layer 3 Non-PoE Switch will be added once available.
Key Specification
| Product Category | Layer 3 | Warranty | 5 years |
|---|---|---|---|
| Total number of RJ45 ports | 24 | Total number of optical ports | 4 |
| Number of 1GE combo ports | No | Number of 1GE SFP ports | 4 |
| Number of 10GE SFP+ ports | No | Number of 10/100BASE-T ports | No |
| Number of 10/100/1000BASE-T ports | 24 | Number of 10/100/1000/2500BASE-T ports | No |
| Number of 100/1000/2.5G/5G/10GBASE-T ports | No | Forwarding rate | 41.66 Mpps |
| Switching capacity | 56 Gbps(bit/s) | MTBF | 400,000 hours |
| Operating temperature | 0°C to +50°C (32°F to 122°F) | Altitude | Operating altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.) Storage altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.) |
| Surge protection | Service port: ±6 kV for common mode Power connector: ±6 kV for both common mode and differential mode | PoE watchdog | No |
| Jumbo frame length (MTU) | 9216 bytes (interface configuration mode) | Port isolation | Yes |
| Broadcast storm control | Yes |
Product Resources
Deployment Support
Optional setup guidance and after-sales support available from Star-Link Group.
Layer 3 Managed
Built for structured business network deployment and maintenance.
SFP Uplink
4 x SFP ports support flexible fibre or switch backbone planning.
Cloud Managed
Ruijie Cloud management supports remote monitoring and maintenance.
Free remote configuration is available for your first project and for projects involving three or more devices. Complimentary training is also available if required. Appointments are essential for all configuration and training sessions.
Note: Setup guidance and pre-configuration service are provided by Star-Link Group and are not built-in product features. Please email support@star-link.net.au if you would like to discuss your setup.
Reviews
There are no reviews yet.
